Calcium fluoride Right angle prism 12*12*14mm Optical path conversion visible light infrared band Size can be customized

Calcium fluoride Right angle prism

specification: 12*12*14mm Right angle prism

Roughness: about 10 angstroms

Dimensional tolerance: +0.1/-0.1

Thickness tolerance: ±0.1

Parallelism: less than 5 seconds or higher

Finish: 40-20 or other

Face type: 1/4 entry or higher

Chamfer: 0.25mm × 45°

The prism is made of CaF2 crystal material with very small angular tolerance. It has a good projection in the range of UV, visible and NIR-FIR (near infrared, far-infrared), which can deflect the image formed by the optical path or optical imaging system 90°. Right-angle prisms can also be used for applications such as composite images and inexpensive beams.Size can be customized.

​
